Product Details:
Payment & Shipping Terms:
|
| Material:: | Hadfield Steel | After Warranty Service: | Video Technical Support, Online Support |
|---|---|---|---|
| Feature:: | High Duarability,Best Quality,High Power | Application:: | Crawler Excavator |
| Total Weight Wiith Sparepart:: | 145KG | Apply To:: | 2.5-4.5 Ton Excavator |
| High Light: | 2.5T Excavator Breaker Hammer,Hitachi Excavator Breaker Hammer,Hadfield Steel Hydraulic Breaker Hammer |
||
Feature
The detail for NTK530 as blow:
| TYPE | UNIT | NTK450 | NTK530 | NTK680 | NTK750 | NTK1000 | ||
| UNIT WEIGHT | KG | 95 | 145 | 275 | 373 | 768 | ||
| Requierd Oil Flow | L/min | 20-40 | 20-50 | 40-70 | 50-90 | 80-110 | ||
| Working Pressure | kg/cm | 90-120 | 90-120 | 110-140 | 120-150 | 150-170 | ||
| Impact Rate | b.p.m | 700-1200 | 600-1100 | 500-900 | 400-800 | 350-700 | ||
| Hose Diameter | in. | 1/2 | 1/2 | 1/2 | 1/2 | 3/4 | ||
| Chisel Diameter | mm | φ45 | φ53 | φ68 | φ75 | φ100 | ||
| Chisel Length | mm | 500 | 580 | 700 | 750 | 1000 | ||
| Naise 85dB(A)-Distance | m | 3-6 | 4-8 | 5-10 | 6-12 | 7-14 | ||
| Applicable Excavator | m³TON | 0.03-0.1 | 0.06-0.2 | 0.15-0.3 | 0.2-0.35 | 0.4-0.6 | ||
| 0.8-1.5 | 2.5-4.5 | 4-7 | 6-7 | 11-16 | ||||
