Product Details:
Payment & Shipping Terms:
|
| Dimension:: | Depending On The Specification Of Tool Maker | Chisel Type:: | Moil Point, Blunt Tool, Flat, Wedge |
|---|---|---|---|
| Mechanical Properties:: | Surface Hardness HRC51± 3 | Material:: | 42CrMo |
| Application:: | Construction Machine | Heat Treatment:: | Austenting Temperature 810~850 (20min/inch) |
| Suitable Excavator(ton): | 20-100T | After Warranty Service:: | Video Technical Support, Online Support |
| High Light: | 42CrMo Excavator Breaker Chisel,140*1250 Excavator Breaker Chisel,140*1250 Hydraulic Rock Breaker Chisels |
||
We have hydraulic breaker chisel for following items
| Krupp | HM45,HM50/60,HM60/75,HM85,HM130/135,HM170/185,HM200,HM300/301, |
| HM400/401,HM550,HM560CS,HM580,HM600/601,HM700 | |
| RAMMER | S21,S20/22,ROX100,S23,S25,S26/,ROX400,S29,S52/,ROX700, |
| S54/700,S55,S56/800,S82/1400 | |
| N.P.K | H1XA,H2XA,H3XA,H4X,H6XA,H7X,H8XA,H10XA |
| INDECO | MES350,HB5,MES553,MES621,MES1200,HB12,HB19,MES1800,HB27,MES2500 |
| MONTABERT | BRH30,BRH40,BRH45,BRH60,BRH76/91,BRP100,BRP130,BRP125,BRH250, |
| RH501,BRH620, BRH625,BRH750,BRV32 | |
| STANLEY | MB125,MB250/350,MB550,MB656,MB800,MB1550, |
| MB1950/1975,MB30EX,MB40EX | |
| FURUKAWA | HB05R,HB1G,HB2G,HB3G,HB5G,HB8G,HB10G,HB15G,HB20G |
| HB30G,HB40G,HB50G, | |
| TOKU/TOYO | TNB1E,TNB2E,TNB4E,TNB6E,TNB7E,TNB14E,TNB22EA,THBB101, |
| OKADA | OUB301,OUB302,OUB303,OUB305,OUB308,OUB310,OUB312,OUB316,OUB318, |
| SOOSAN | SB10,SB20,SB30,SB35,SB40,SB43,SB45,SB50,SB60,SB70,SB81, |
| SB100,SB121,SB130,SB151 | |
| KWANGLIM | SG200,SG300,KSG350,SG400,SG600,SG800,SG1200,SG1800,SG2100,SG2500, |
| DAEMO | DMB03,DMB04,DMB06,S150-V,S300-V,S500-V,S700-V,S900-V,S1300-V,S1800-V |
| HANWOO | RHB301,RHB302,RHB303,RHB304,RHB305,RHB306,RHB308,RHB309,RHB313, |
| DAINONG | D30,D50,D60,D70/90,D110,D130,D160,T180,K20 |
| K25,K30,K50,K80,K120,K55S,K40S, |
| Sort Name | Excavator Breaker Chisel |
| Main Size | Customized |
| Material | 42Cr, 42CrCo |
| Hardness |
CHISEL POINT'S HARDNESS: HRC53-56 TAIL'S HARDNESS: HRC48-51 |
| Different type |
KRUPP, ATLAS COPCO, RAMMER, SANDVIK, MONTABERT, INDECO, N.P.K, TOKU, DAEMO... |
| Advantage: | Superior designs Excellent wear-resistant materals Different kinds of teeth system for selection Fit for all applications,including earth,sands,limestone,gold mines and hot slag Best choice for value |
| Main Business | Motor Grader Blades and End Bits, Dozer Cutting Edge, Loader Bucket Edges, Excavator Cutting edge, Scraper Cutting Edge, Bucket Teeth, Bolts and Nuts, Pins&Retainer |
| Brand | CAT, CASE, KOMATSU, HITACHI, HYUNDAI, JCB, KOBELCO, LIEBHERR, TEREX, O&K, VOLVO, BUCYRUS, P&H, DOOSAN, DAEWOO, ATLAS, XUGONG, LIUGONG, SANY, ZOOMLION, etc.. |
| Package | Cutting edge and end bits:PLYWOOD PALLETS; Bucket Teeth And Adapters:PLYWOOD CASES; Bolts And Nuts/Pins&Retainers:PLYWOOD CASES; |
| Payment | L/C,D/P,T/T |
Are you a factory or trading company?
We are a professional manufacturer.
Can you make products with our brand?
Surely,we are welcome to cooperate as customized service.
What services can you provide?
1. One year warranty,free replacement for broken ones with abnormal wear life.
2. Provide technical support to our customers.
3. Help you to explore your market.
4. VIP treatment to our exclusive agent.
