| Chisel Type:: | Moil Point, Blunt Tool, Flat, Wedge | Application:: | Excavator |
|---|---|---|---|
| Material: | 42CrMo | Stock: | Enough Stock |
| Specification: | 25.4*125mm | Chemical Component: | Beneparts Will Provide Test Report Before Shipment |
| High Light: | Conical Hydraulic Rock Breaker Chisel,Sb35 Hydraulic Rock Breaker Chisel,Conical Excavator Hammer Chisel |
||
Product Description
1. Material: 40Cr or 42CrMo
2. Dimension: Depending on the specification of Tool Maker
3. Chisel type: Moil Point, Blunt Tool, Flat, wedge
4. Heat Treatment:
Austenting Temperature 810~850 (20min/inch) Cooling Water oil cooling Tempering 250~300 (1hr/inch)
5. Mechanical Properties:
Surface Hardness HRC51± 3
Core Hardness HRC35± 3 Tensile strength(min) 1250N/mm² Yield point (min) 950N/mm²
Elongation 10~14% Reduction of Area 35~40% Impact work 23~28 ft1b Grain size 7.0~8.0
We have hydraulic breaker chisel for following items
|
Krupp
|
HM45,HM50/60,HM60/75,HM85,HM130/135,HM170/185,HM200,HM300/301, |
| HM400/401,HM550,HM560CS,HM580,HM600/601,HM700 | |
RAMMER |
S21,S20/22,ROX100,S23,S25,S26/,ROX400,S29,S52/,ROX700, |
| S54/700,S55,S56/800,S82/1400 | |
| N.P.K | H1XA,H2XA,H3XA,H4X,H6XA,H7X,H8XA,H10XA |
| INDECO | MES350,HB5,MES553,MES621,MES1200,HB12,HB19,MES1800,HB27,MES2500 |
MONTABERT |
BRH30,BRH40,BRH45,BRH60,BRH76/91,BRP100,BRP130,BRP125,BRH250, |
| RH501,BRH620, BRH625,BRH750,BRV32 | |
STANLEY |
MB125,MB250/350,MB550,MB656,MB800,MB1550, |
| MB1950/1975,MB30EX,MB40EX | |
FURUKAWA |
HB5G,HB8G,HB10G,HB15G,HB20G,HB30G,HB40G,HB50G, F12,F19,F22,F22 |
| F27,F35,F45,F70 | |
| TOKU/TOYO | TNB1E,TNB2E,TNB4E,TNB6E,TNB7E,TNB14E,TNB22EA,THBB101, |
| OKADA | OUB301,OUB302,OUB303,OUB305,OUB308,OUB310,OUB312,OUB316,OUB318, |
| SOOSAN | SB10,SB20,SB30,SB35,SB40,SB43,SB45,SB50,SB60,SB70,SB81, |
| SB100,SB121,SB130,SB151 | |
| KWANGLIM | SG200,SG300,KSG350,SG400,SG600,SG800,SG1200,SG1800,SG2100,SG2500, |
| DAEMO | DMB03,DMB04,DMB104/DMB210,S150-V,S300-V,S500-V,S700-V,S900-V,S1300-V, |
| HANWOO | RHB301,RHB302,RHB303,RHB304,RHB305,RHB306,RHB308,RHB309,RHB313, |
| MSB | SAGA120,SAGA180, SAGA200,SAGA300,SAGA350 |
| MS200,MS250, MS300,MS550,MS600, MS700,MS750 |
FAQ
Q: Are you a manufacturer?
A: Yes,our factory was established in 2010.
Q: Are you sure your product will fit my excavator?
A: Our equipments are suitable for most excavators. Show us your excavator model, we'll confirm the solution.
Q: Can you produce according to customers' design?
A: Sure, OEM/ODM service available. We are professional manufacturer in Yantai.
Q: What's the MOQ and payment terms?
A: MOQ is 1set. Payment via T/T,L/C, Western Union accepted, other terms can be negotiated.
Q: How about delivery time?
A: 5-25 work days after the payment.
Q: How about the package?
A: Our equipments wrapped by stretch film, packed by pallet or polywood case; or as requested.
Q: Which country have you exported?
A: Saudi Arabia, America, Thailand, Cyprus, India, Canada, Australia, Peru, Egypt, Brazil, Mexico, Iran, South Africa, etc.
