Product Details:
Payment & Shipping Terms:
|
| Type: | Hydraulic Sheet Pile Driver | Service:: | OEM Service Availables |
|---|---|---|---|
| Efficiency: | High Efficiency | Suitable Excavator: | 20-24ton |
| Price: | Negotiable | Packaging Details: | Standard Packing |
| Delivery Time: | 5-8 Work Days | Place Of Origin: | CHINA |
| High Light: | 24 Ton Excavator Pile Driver,OEM Excavator Pile Driver,24 Ton Hydraulic Sheet Pile Driver |
||
Hydraulic Press Driver Excavator Pile Hammer Driver OEM Service
Parameter
| Item | FB30 | FB40 |
| Eccentric Moment | 40Nm | 85Nm |
| Centrifugal Force | 300kN | 570kN |
| Amplitude | 6.8mm | 14mm |
| Frequency | 2800rpm | 2800rpm |
| Pressure | 240-260kg/cm2 | 240-260kg/cm2 |
| Oil Flow | 155-200L/min | 200-255L/min |
| Turning Angle | 360degree | 360degree |
| Package Size | hammer with clamp:1450mm*1550mm*1650mm | hammer with clamp:1650mm*1700mm*1950mm |
| vice arm: 2700mm*800mm*1200mm | vice arm: 3350mm*850mm*1350mm | |
| Total: 7.41cube meters | Total: 8.81cube meters | |
| Net Weight | hammer with clamp: 2000kg | hammer with clamp: 2800kg |
| vice arm: 500kg | vice arm: 650kg | |
| Total: 2500kg | Total: 3450kg | |
| Suitable excavator | 20-35tons | 30-50tons |
1, High quality material (Q345b) provide high steel toughness and good abrasive resistance.
2, Easy to install , easy to operate.
3, Imported Motor, good endurance, high rotate speed, big torque, provide higher and faster agitate strength.
4, Can deal with steel sheet pile ,concrete sheet pile, steel pipe, by different shape pile cap.
5, Can be single chuck , adjustable double chuck , and mounted on crane for larger operating range.
A. 7Days*24Hours after-sales service by email or phone.
B. Your inquiry will be replied in 24 hours during workdays.
C. Professional technical team with many year's experience at your service.
D. OEM ODM Service available.
E. Warranty: 6 months, beyond the warranty period, all spare parts offered to you with our cost price (not including freight cost).
