Product Details:
Payment & Shipping Terms:
|
| Marketing Type: | New Product 2021 | Service: | OEM, ODM Service Available |
|---|---|---|---|
| Machinery Test Report: | Provided | System: | Hydraulic-Gas System |
| Advantage: | Safe, Low Noice, High Frequency | Applicable Industries: | Construction Works , Energy & Mining |
| High Light: | Jack Excavator Breaker Hammer,OEM Excavator Breaker Hammer,Excavator Hydraulic Rock Hammer Attachment |
||
| model | total weight | length | diameterof tool | suitable carrier |
| unit | kg | mm | mm inch | ton |
| HWX100 | 53 117 | 918/1086/1190 | 10 1.57 | 0.8-2.5 |
| HWX200 | 71 156 | 1090/1235/1331 | 45 1.77 | 1.2-3.0 |
| HWX300 | 89 196 | 1178/1344/1417 | 53 2.08 | 2.5-4.5 |
| HWX400 | 156 343 | 1373/684/1660 | 68 2.68 | 4-7 |
| HWX400A | 165 363 | 1373/1684/1660 | 68 2.68 | 4-7 |
| HWX430 | 214 471 | 1515/1706/1712 | 75 2.95 | 6-9 |
| HWX435 | 215 473 | 1630/1738/1717 | 75/80 2.95/3.15 | 6-9 |
| HWX435A | 225 295 | 1630/1738/1717 | 75/80 2.95/3.15 | 6-9 |
| HWX450 | 282 620 | 1735/2120/2074 | 85 3.35 | 7-14 |
| HWX450A | 301 662 | 1735/2120/2074 | 85 3.35 | 7-14 |
| HWX800 | 479 1054 | 1994/2387/2354 | 100 3.94 | 10-15 |
| HWX800A | 503 1107 | 1994/2387/2354 | 100 3.94 | 10-15 |
| HWX1600 | 620 1364 | 2285/2673/2578 | 125 4.92 | 15-18 |
| HWX2000 | 850 1870 | 2423/2900/2847 | 135 5.31 | 18-26 |
| HWX2000F | 846 1861 | 2427/2656/2646 | 135 5.31 | 18-26 |
| HWX2200 | 920 2024 | 2480/2866/2793 | 140 5.51 | 18-26 |
| HWX2200A | 956 2103 | 2480/2866/2793 | 140 5.51 | 18-26 |
| HWX3000 | 1092 2402 | 2640/2897/3002 | 150 5.91 | 27-35 |
| HWX4500 | 1960 4300 | 3184/3812/3723 | 175 6.89 | 35-40 |
| HWX8000 | 2663 5842 | 3420/4021/- | 195 7.68 | 45-60 |
Through bolts: Longer service life by to applied heat treatment.
Back head: Material: 20CrMo, impact energy is accumulated due to charged nitrogen gas in the block.
Front Head: Using 20CrMo material, high quality with long life using.
Valve: We adopt production process by grinding machine, with high precision.
Cylinder body: Material: 20CrMo, it is best quality material.
Piston: Longer service life by optimized design and high quality special steel.
Front Head: Using 20CrMo raw material, which are provided by domestic famous manufacturer, forging again and again to make internal organization more tight and increasing the hydraulic breaker wear-resistance.
Chisel: The specially heat treated chisel is directly applied to break rocks. There are four types for choosing: Moil, Blunt, Flat, Conical Point. The material is 42Crmo.
Main Body: Including Front head, cylinder and back head. Ensure your breaker will be in best performance
Seal Kit: We can supply both Parker and NOK seal kit which are most famous brand in the business line
Q: Are you a manufacturer?
A: Yes,our factory was established in 2010.
Q: Are you sure your product will fit my excavator?
A: Our equipments are suitable for most excavators. Show us your excavator model, we'll confirm the solution.
Q: How about your products warranty?
A: 12 months warranty for hydraulic breaker, beyond the warranty period.
Q: Can you produce according to customers' design?
A: Sure, OEM/ODM service available. We are professional manufacturer in Yantai.
Q: What's the MOQ and payment terms?
A: MOQ is 1set. Payment via T/T,L/C, Western Union accepted, other terms can be negotiated.
Q: How about delivery time?
A: 5-25 work days after the payment.
Q: How about the package?
A: Our equipments wrapped by stretch film, packed by pallet or polywood case; or as requested.
Q: Which country have you exported?
A: Saudi Arabia, America, Thailand, Cyprus, India, Canada, Australia, Peru, Egypt, Brazil, Mexico, South Africa, etc.
